DC Voltage Measurement Module - ZVS-DC-08
The ZVS-DC-08 module has been developed to measure the voltage that can be found in the circuit breaker control cabinet. Able to measure voltage up to 300 Volts, this module is a real DC voltmeter.
Main advantages
- Thanks to its galvanic isolation, it is possible to measure any differential voltage. Its 8 measurement range will allow you to scale the measured voltage and thereby obtain a very precise value.
- The ZVS-DC-08 is directly connected to one of the analog inputs of the CBA-32P. The results can be viewed on your computer screen with our CBA WinŠ software.
- With this module, you will be able to view the voltages of your circuit breaker and find the fault more quickly in case of malfunction.
Technical Features
- Input voltage : 0 - 300VDC, distributed with 8 scales. (20, 30, 50, 100, 150, 200, 250 and 300 Volts).
- Output voltage : 0 - 10VDC.
- Response time : 0.8ms.
- Supply voltage: 120VAC/60Hz or 220VAC/50Hz.
- Operating temperature : -10°C to +65°C.
- Galvanically isolated.
Commercial references
Product reference : ZVS-DC-08
 DC Voltage Measurement Module |
* Specifications and appearance may change without notice
